APC APC 900VA LCD – BR900GI LCD

Stok
Kategori APC
Tentukan pilihan yang tersedia!
INFO HARGA
Silahkan menghubungi kontak kami untuk mendapatkan informasi harga produk ini.
Pemesanan yang lebih cepat! Pesan Langsung
Bagikan ke

APC APC 900VA LCD – BR900GI LCD

APC APC 900VA LCD – BR900GI LCD

Technical Specifications

Output

Max Configurable Power (Watts)

540 Watts / 900VA
Output Frequency (sync to mains)

50/60 Hz +/- 1 Hz Unsynchronised, 50/60 Hz +/- 3 Hz Sync to mains
Load Crest Factor

3 : 1
Topology

Line interactive
Waveform type

Stepped approximation to a sinewave
Transfer Time

8 ms typical : 10 ms maximum
Bypass

Built-in bypass

Input

Input frequency

50/60 Hz +/- 3 Hz Auto-sensing
Input voltage range for main operations

156 – 300 Adjustable, 176 – 294V
Number of Power Cords

1

Batteries & Runtime

Battery type

Lead-acid battery
Typical recharge time

8hour(s)
Replacement Battery

Expected Battery Life (years)

3 – 5
RBC Quantity

1
Battery Charge Power (Watts)

20 Watts
Battery Volt-Amp-Hour Capacity

157

Communications & Management

Interface Port(s)

Optional Simple Signalling RS232 cable, USB
Control panel

Multifunction LCD status and control console
Audible Alarm

Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm

Surge Protection And Filtering

Surge energy rating

613Joules
Data Line Protection

RJ11 analog phone line for phone/fax/modem/DSL, RJ45 network line – 10/100/1000 Base-T Ethernet
Filtering

Full time multi-pole noise filtering : 10% of IEEE surge let-through : zero clamping response time: instantaneous

Physical

Maximum Height

250MM, 25.0CM
Maximum Width

100MM, 10.0CM
Maximum Depth

382MM, 0.0CM
Net Weight

10.72KG
Shipping weight

11.7KG
Shipping Height

337MM, 33.7CM
Shipping Width

225MM, 22.5CM
Shipping Depth

487MM, 48.7CM
Color

Black
Master Carton Units

1.0
Pallet Dimensions

46inches
Pallet Weight

867.03lbs.
Units per Pallet

30.0
SCC Codes

10731304279591

Environmental

Operating Temperature

0 – 40 °C
Operating Relative Humidity

0 – 95 %
Operating Elevation

0 – 2999.8meters
Storage Temperature

-15 – 45 °C
Storage Elevation

0 – 14999.8meters
Audible noise at 1 meter from surface of unit

45.0dBA

Conformance

Approvals

A-Tick, C-Tick, CE, GS Mark
Equipment protection policy

Lifetime : 150000 euros, Lifetime : 200000 AUD, Lifetime : 75000 GBP
Standard warranty

2 years repair or replace, 3 years repair or replace for European Union countries

Sustainable Offer Status

RoHS

Compliant
PEP

Available in Documentation tab
EOLI

Available in Documentation tab
