UPS PROLINK IPS1200
| Stok | |
| Kategori | PROLINK |
UPS PROLINK IPS1200
UPS PROLINK IPS1200
Deskripsi PROLINK IPS1200 1200VA IPS Inverter
PROLINK IPS1200 1200VA INVERTER POWER SUPPLY WITH LED AND LCD
– Simulated sine wave inverter
– 10A charging current
– LCD and LED indicators
– Overload and short circuit protection
– Auto restart while AC is recovering
Specification:
– Model : IPS1200
– Capacity : 1200VA
– Input :
Nominal Voltage : 220/ 230/ 240VAC
Voltage Range :
Narrow Range : 170 280 VAC (UPS mode)
Wide Range : 90 – 280VAC
– Output :
Nominal Voltage : 230VAC
Output Voltage Regulation (Battery Mode) : +10%/ -18%
Frequency : 50Hz or 60Hz
Frequency Regulation : +/-0.1 Hz (Bat. Mode)
Transfer Time : 10 – 20ms Typical, 40ms (max)
Waveform : Simulated Sinewave
– Battery :
Charger Current : 10Amp / 20Amp (Selectable)
DC Voltage : 12V
Overcharge Protect : 15V
– Indication :
LED Display:
Fault Red Lighting
Battery Mode – Yellow
Low Battery Yellow flashing
Shutdown Mode Yellow flashing
Charging Mode – Green flashing
Overload – Red flashing
LCD Display :
Input Voltage, Output Voltage, Load level, Battery level, Fault alarm
– Alarm :
Sounding :
Overload – Sounding every 0.5 second
Low Battery – Sounding every 2 secounds
Overcharging Fault Continuously sounding
– Efficiency :
AC to AC : >95%
DC to AC : >80%
– Physical :
Dimension (mm) D x W H : 293 x 231.5 x 82.5
Net Weight (kgs) : 2.35
– Environment :
Humidity : 0~95% Relative Humidity. 0~40C
Noise Level : Less than 50dBA
– Package Content :
Included :
1 x IPS1200 / IPS2400 LCD Inverter
1 x Battery Cable (Set)
1 x User Manual
